A-Tekniikka Spare parts catalog

1. Frame assembly

  • 1-002-1033 Curved slide 1033

  • 1-002-1150 Curved slide 1150

  • 1-002-1250 Curved slide 1250

  • 1-002-1500 Curved slide 1500

  • 1-002-1800 Curved slide 1800

  • 1-002-2000 Curved slide 2000

  • 1-006 Bushing

  • 1-008-4000 Linear actuator

  • 1-008-8000 (1-008) Linear actuator

  • 1-049 (3-007) Inner protection plate

  • 1-050 (3-010) Outer protection plate

2. Tyre handling

  • 2-001 Rim bearing assembly (moving)

  • 2-001-1 Axis

  • 2-001-10 Seal 60x90x8

  • 2-001-10 (2-023-7) Seal 60x90x8

  • 2-001-11 Bearing body

  • 2-001-2 (2-009) Bushing

  • 2-001-3 Shaft

  • 2-001-4 Screw mod.

  • 2-001-5 Nut

  • 2-001-5 (2-023-2) Nut

  • 2-001-6 Locking washer

  • 2-001-6 (2-023-1) Locking washer

  • 2-001-7 Ring

  • 2-001-8 Bearing 30208

  • 2-001-9 Bearing 33210

  • 2-002 (2-002-2) Flange assembly Left side

  • 2-002-4 (2-023-13) Seal

  • 2-004 (2-001-15) Axis cover

  • 2-006 Body at end joint

  • 2-008-L (2-008) Left elbow joint bar

  • 2-008-R (2-013) Right elbow joint bar

  • 2-009-16 (2-007) Bushing, H16.0

  • 2-009-20 (2-009) Bushing, H20.0

  • 2-009-8.5 (2-022) Bushing, H8.5

  • 2-010-55 (2-010) Joint axis, L55

  • 2-010-73 (2-011) Joint axis, L73

  • 2-013-15 (2-005) Distance piece, H15

  • 2-013-28 (2-004) Distance piece, H28

  • 2-014 Body of moving joint

  • 2-016 (2-016-2) Bearing system

  • 2-016-1 Body of bearing system

  • 2-016-2 (2-020-1) Bearing

  • 2-017 Counter support

  • 2-018 Inductive sensor E2A-S08KS02-M1-B1

  • 2-019 Inductive sensor

  • 2-020 (2-021) PN cylinder

  • 2-025 (2-023) Rim bearing assembly (stat.)

  • 2-025-1 (2-023-3) Ring

  • 2-025-2 (2-023-4) Seal

  • 2-025-3 (2-023-8) Ring

  • 2-025-4 (2-023-9) Bearing body

  • 2-025-5 (2-023-10) Axis

  • 2-026 (2-002-1) Flange assembly right side

  • 2-027 (2-041) Tooth belt pulley

  • 2-028 Pressure sensor

  • 2-029 (2-027) Pressure sensor support

  • 2-031 (2-024) Rim bearing unit connector

  • 2-040-13 (2-029) Rim pair for 13" tyres

  • 2-040-14 (2-030) Rim pair for 14" tyres

  • 2-040-15 (2-031) Rim pair for 15" tyres

  • 2-040-16 (2-032) Rim pair for 16" tyres

  • 2-040-17 (2-033) Rim pair for 17" tyres

  • 2-040-18 (2-034) Rim pair for 18" tyres

  • 2-040-19 (2-035) Rim pair for 19" tyres

  • 2-040-20 (2-036) Rim pair for 20" tyres

  • 2-040-21 (2-037) Rim pair for 21" tyres

  • 2-040-22 (2-038) Rim pair for 22" tyres

  • 2-042-10 Rim spacing ring, 10 mm

  • 2-042-20 (2-040-2) Rim spacing ring, 20 mm

  • 2-042-40 (2-040-4) Rim spacing ring, 40 mm

  • 2-052 (2-056) Conveyor sliding guide

  • 2-053-C (2-049) Pneumatic cylinder (conveyor)

  • 2-061 (2-010) Sprocket

  • 2-062 (2-060) Conveyor motor

  • 2-063 (2-061) Gearbox

  • 2-076 Scissor jack

  • 2-080-1 (2-006) Chain lock (single)

  • 2-080-2 (2-007) Chain lock (double)

  • 2-080-4-383 (2-042) Transfer bar with magnetic tip

  • 2-080-4-423 (2-042) Transfer bar with magnetic tip

  • 2-080-5-383 (2-043) Transfer bar

  • 2-080-5-423 (2-043) Transfer bar

  • 2-080-6 (2-047) Tyre support

  • 2-080-7 (2-048) Tyre support spring

  • 2-083 (2-055) Sensor support

3. Servo drive Y

  • 3-001 Support

  • 3-002 Tooth belt pulley, Y

  • 3-003-100 (3-003) Gearbox LP090-M02

  • 3-003-110 (3-003) A-TEC 110 Gearbox

  • 3-004-100 (3-004) Servo motor SGMAH-04AAA61D-OY

  • 3-004-110 (3-004) Servo motor R88M-K40030H-S2

  • 3-005-100 (3-012) Servo power cable R88-CRWA003C-DE

  • 3-005-110 (3-012) Servo power cable R88A-CAKA003SR-E

  • 3-006-100 (3-013) Servo encoder cable R88-CAWA003S-DE

  • 3-006-110 (3-013) Servo encoder cable R88A-CRKA003CR-E

  • 3-007-100 (3-005) A-TEC 100 Servo motor cover

  • 3-007-110 (3-005) A-TEC 110 Servo motor cover

  • 3-008 Protection plate support

  • 3-009 Distance piece

  • 3-011 Tooth belt 28-AT10-1210

4. Servo drive X

  • 4-002 (4-025) Bearing system

  • 4-002-1 (4-002) Dust seal 70x100x8

  • 4-002-2 (4-003) Bearing 7211 BM

  • 4-002-3 (4-004) Body of bearing system

  • 4-002-5 (4-008) Bearing collar

  • 4-002-6 (4-009) Sealing ring

  • 4-002-7 (4-010) Locking washer

  • 4-002-8 (4-011) Adjustment nut M55x2

  • 4-006 Ball screw assembly SL25x25

  • 4-007 Tooth wheel 27AT5/48-0

  • 4-008 Connecting axis

  • 4-009 (5-003) Joint with bushing and screw

  • 4-013 Tooth belt

  • 4-014 Tooth wheel 27AT/20-2

  • 4-015 Threaded shaft

  • 4-016 Bearing

  • 4-017 Frame

5. Studding unit

  • 5-001-1 (5-001) Studding head carrier

  • 5-001-2 (5-002) Guiding bar with screws

  • 5-001-5 (5-005) Lubrication unit

  • 5-001-6 (5-006) Sensor plate

  • 5-001-7 (5-007) Eccentric roller

  • 5-001-8 (5-008) Centric roller

  • 5-002 (5-004) Cylinder clamp

  • 5-005-1 (5-009) Upper bar

  • 5-005-2 (5-017) Short connection rod assembly

  • 5-005-3 (5-011) Shock absorber

  • 5-005-4 (5-012) Lower bar

  • 5-005-5 (5-013) Rubber bumper

  • 5-005-50 (5-050) Cylinder packet assembly

  • 5-005-6 (5-014) Connector

  • 5-005-7 (5-018) Upper pneumatic cylinder ADVUL-50-50-PA

  • 5-005-8 (5-019) Long connection rod

  • 5-005-9-50 (5-020) Lower pneumatic cylinder ADVU-50-50-P-A

  • 5-005-9-65 (5-020-P) Lower pneumatic cylinder ADVU-50-65-P-A

  • 5-016 (2-054) Inductive sensor

  • 5-016 Inductive sensor MZET 12404

  • 5-017 (4-021) Limit sensor E2A-S08KS02-WP-C2

  • 5-018 (4-022) Calibration sensor E2A-S08KS02-WP-C1

  • 5-021-8-50 Studding bar

  • 5-021-8-52 Studding bar

  • 5-021-8-55 Studding bar

  • 5-021-8-57 Studding bar

  • 5-021-8-65 Studding bar

  • 5-021-8-67 Studding bar

  • 5-021-8-70 Studding bar

  • 5-022-8-120-6.5 Studding pin

  • 5-022-8-90-5.8 Studding pin

  • 5-025-8.4 (5-025) Studding head

  • 5-035 Joint ring

  • 5-036 O-ring 21x4

  • 5-037 Studding finger

  • 5-047-8.4 (5-047-8) Stud feeder assembly

6. Stud handling system

  • 6-001 Adjustment bar

  • 6-002 Shaft

  • 6-003 Support bar

  • 6-004-9.4 (6-004) Suction socket

  • 6-007 Feeder cone

  • 6-007-A Adjustable feeder cone

  • 6-008 Circular vibrating base

  • 6-009 Phase angle controller

  • 6-010 Stud tube

  • 6-011 Stud tube D13/9.5

  • 6-016-1 (6-016) Ejector body

  • 6-016-2 (6-017) Ejector part upper

  • 6-016-4 (6-018) Ejector part lower

  • 6-016-6 Silencer

  • 6-016-9.2 Ejector assembly

  • 6-021-12 Stud sensor SIA12-CE

  • 6-024-12 Joint tube

  • 6-025 Rubber rope loop

7. Liquid feeding system

  • 7-001 Liquid tank

  • 7-007 Pressure controller

  • 7-008 Pressure gauge

  • 7-009 Check valve

  • 7-017 (7-032) Magnetic valve cable

  • 7-018 Magnetic valve

  • 7-020 Nozzle

  • 7-024 (7-022) Fastening plate

  • 7-025 Flexible support

8. Pneumatic circuits

  • 8-005 Pressure controller

  • 8-009 Pressure gauge

  • 8-009 Pressure gauge

  • 8-010 Pressure controller

  • 8-010 Pressure controller

  • 8-015 Air tank

  • 8-022 Valve

  • 8-031 Flow controller ASN2-01-S

  • 8-032 (8-027) Magnetic valve MFH-5-1/8-B

  • 8-033 Magnetic valve JMFH-5-1/4-B

  • 8-034 Flow controller ASN2-02-S

  • 8-044 Safety valve

  • 8-048 Inflating valve MN1H-2-1-MS

  • 8-051 Solenoid MSFG-24/42-50/60-0D

  • 8-052 Magnetic valve MFH-3-1/4-S

  • 8-055 Pressure switch VPEV

  • 8-058 Magnetic valve MFH-3-1/4-S

  • 8-059 Membrane 670568

  • 8-060 Pressure controller

  • 8-061 Pressure gauge

  • 8-065-18 Silencer

  • 8-066-14 Connector bolt

  • 8-066-18 Connector bolt

  • 8-067 Magnetic valve MFH-3-1/4-S

  • 8-068 Magnetic valve MFH-5-1/4-B

  • 8-079 Manifold

9. Electrical control system

  • 9-010 Power supply 24 VDC 10A

  • 9-011-100 PLC pwer unit C200HW-PA204JPN

  • 9-011-110 A-TEC 110 PLC pwer unit

  • 9-012-100 CPU CS1H-CPU63H

  • 9-012-110 A-TEC 110 CPU

  • 9-012-BAT Battery CS1W-BAT01

  • 9-013 Communication unit CS1W-SCB21-V1

  • 9-014-100 Position control unt CS1W-NC213

  • 9-014-110 A-TEC 110 Position control unt

  • 9-015-100 Input board CS1W-ID231

  • 9-015-110 A-TEC 110 Input board

  • 9-016-100 Output board CS1W-OD232

  • 9-016-110 A-TEC 110 Output board

  • 9-034 Cable XW2Z-100J-B4

  • 9-035 Cable XW2Z-100B

  • 9-036 Cable XW2Z-200B

  • 9-037 Cable XW2Z-100J-A7

  • 9-038 Cable 40J6-2B

  • 9-040 Operating panel NS5-SQ10-V2

  • 9-042 Console F150-KP

  • 9-043-F210 Vision system F210-C15

  • 9-051 Black push-button

  • 9-052 Arrow push-button

  • 9-053 Green push-button

  • 9-054 Red push-button

  • 9-055 Emergency stop push-button

  • 9-056 2 pos. white selector switch

  • 9-057 2 pos. yellow selector switch

  • 9-058 3 pos. white selector switch

  • 9-061 Fixing adapter

  • 9-062 LED element

  • 9-063 Make contact

  • 9-064 Break contact

  • 9-065 Yellow signal

  • 9-070-2 (9-028) LED lamp

  • 9-071-1 LED strip

10. Cameras

  • 10-001-L Left inclined fastener

  • 10-001-R Right inclined fastener

  • 10-002 Adjustable support

  • 10-006-F150 Camera fastener

  • 10-006-FZ Camera fastener

  • 10-007-F150 Camera F150-S1A

  • 10-007-FZ Camera

  • 10-008 Optic lens C1614-M

  • 10-009-F150 Camera cable F150-VS

  • 10-009-FZ Camera cable

  • 10-010 Display

  • 10-011-FZ Machine vision system

11. Quality check stand

  • 11-001 Quality check stand

  • 11-001-1 (11-001) Leg

  • 11-001-10 (11-013) Bracket

  • 11-001-2 (11-002) Fastening bolt

  • 11-001-3 (11-003) Locking pin

  • 11-001-4 (11-004) Adjustable support

  • 11-001-5 (11-005) Vertical axis M16

  • 11-001-6 (11-007) Fork

  • 11-001-7 (11-008) Axis

  • 11-001-8 (11-009) Roller

  • 11-001-9 (11-010) Bearing

12. Teaching equipment

  • 12-001 Joystick

  • 12-002-2 (12-003) Teaching head pin

  • 12-002-SD (12-002) Teaching head SD

13. Tool box

  • 00100192 (13-001) OKU EP-8 Hand studding gun
